TLP161J(TPL,U,C,F)

Name: TLP161J(TPL,U,C,F)
Brand: Toshiba Semiconductor and Storage
SKU: 370089
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP161J(TPL,U,C,F)
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Triac, SCR Output
Description	Optoisolator Triac Output 2500Vrms 1 Channel 6-MFSOP, 4 Lead
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators
Family	Optoisolators - Triac, SCR Output
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel(TR)
Output Type	Triac
Zero Crossing Circuit	Yes
Number of Channels	1
Voltage - Isolation	2500Vrms
Voltage - Off State	600V
Static dV/dt (Min)	200V/μs
Current - LED Trigger (Ift) (Max)	10mA
Current - On State (It (RMS)) (Max)	70mA
Current - Hold (Ih)	600μA (Typ)
Voltage - Forward (Vf) (Typ)	1.15V
Current - DC Forward (If) (Max)	50mA
Operating Temperature Range	-40°C ~ 100°C
Mounting Style	SMD/SMT
Package	6-SOIC (0.173", 4.40mm Width) 4 Leads
Manufacturer Device Package	6-MFSOP, 4 Lead
Approvals	UR
Win Source Part Number	218018-TLP161J(TPL,U,C,F)
Family Name	TLP161J
Introduction Date	May 15, 2001
ECCN	EAR99
Country of Origin	Japan
Estimated EOL Date	2019
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian TLP161J(TPL,U,C,F) CAD Model

Alternative Products

Description

The Toshiba Semiconductor and Storage 218018-TLP161J(TPL,U,C,F) is an isolator electronic component with a triac output type.

Voltage Isolation: 2500Vrms
Current - DC Forward (If) (Max): 50mA
Voltage - Forward (Vf) (Typ): 1.15V
Supply and Demand Status: Sufficient
Category: Optoisolators - triac, SCR output
Operating Temperature Range: From -40°C to 100°C
Package: Reel-TR
Package Details: 6-SOIC (0.173", 4.40mm width) 4 leads, manufacturer device package of 6-MFSOP, 4 lead
Approvals: UR
ECCN: EAR99
