TC4S81F

Name: TC4S81F
Brand: Toshiba Semiconductor and Storage
SKU: 356634
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	TC4S81F
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Logic - Gates and Inverters
Description	AND Gate 1-Element 2-IN CMOS 5-Pin SMV / IC GATE AND 1CH 2-INP SMV
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel - TR
Status	Obsolete(EOL)
Logic Type	AND Gate
Number of Circuits	1
Number of Inputs	2
Supply Voltage - Operating	3 V to 18 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	3.4mA, 3.4mA
Logic Level - Low	1.5 V to 4 V
Logic Level - High	3.5 V to 11 V
Max Propagation Delay @ V, Max CL	80ns @ 15V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	SMV
Dimension	SC-74A, SOT-753
Win Source Part Number	043010-TC4S81F
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	TC4S81
Introduction Date	April 14, 1997
ECCN	EAR99
Country of Origin	Japan
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian TC4S81F CAD Model

Alternative Products

Description

The TC4S81F is a high-speed AND gate manufactured by Toshiba Semiconductor and Storage.

Circuits Number: Single
Mounting Type: Surface-Mount Device (SMD)
Inputs Number: Two
Current: 3.4mA (High and Low)
Maximum Propagation Delay: 80ns @ 15V and 50pF
Quiescent Current: 1μA
Voltage Range: 3V to 18V
Family: TC4S81
Category: Integrated Circuits
Status: No longer in production (EOL)
Popularity: High (62 percent)
