Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Translator Type Voltage Level
Channel Type Bidirectional
Channels per Circuit 4
Voltage - VCCA 1.65V ~ 3.6V
Voltage - VCCB 2.3V ~ 5.5V
Output Type Open Drain, Push-Pull
Data Rate 24Mbps
Temperature Range - Operating -40°C ~ 85°C
Features Auto-Direction Sensing
Mounting Style SMD
Manufacturer Package 14-SOIC
Supplier Device Package 14-SOIC
Family Part Number TXS0104
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1275138-TXS0104ED
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Communications & Networking, Portable Devices, Consumer Electronics, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian TXS0104ED CAD Model

Description

Product Overview: Texas Instruments TXS0104ED Bidirectional Voltage-Level Translator

The Texas Instruments TXS0104ED is a bidirectional voltage-level translator designed for multi-voltage digital system applications. This device provides a versatile solution for communication between devices operating at different voltage levels, ranging from 1.65V to 3.6V on the A side (VCCA) and from 2.3V to 5.5V on the B side (VCCB). With its auto-direction sensing and non-preferential power-up sequencing, the TXS0104ED ensures a smooth interface between incompatible I/Os and simplifies the design process for system engineers.

Featuring four bidirectional channels, the TXS0104ED is capable of automatic direction sensing, which eliminates the need for a direction control signal. This functionality is particularly beneficial in applications where the data flow can change dynamically, such as I2C, SPI, or other serial interfaces. The device's low on-state resistance provides minimal signal distortion, ensuring high signal integrity for critical applications.

One of the key advantages of the TXS0104ED is its support for partial power-down operation. This feature allows one side of the translator to be inactive while the other remains operational, thereby conserving power when the full translator functionality is not required. This is especially useful in battery-operated devices where power efficiency is paramount.

The TXS0104ED is designed with ESD (Electrostatic Discharge) protection exceeding JESD 22, which safeguards the device against the damaging effects of static electricity. This makes the translator well-suited for use in environments where ESD events are a concern, such as in industrial and consumer electronics.

Available in a compact, space-saving 14-pin TSSOP (Thin Shrink Small Outline Package), the TXS0104ED is ideal for applications with limited PCB (Printed Circuit Board) space. The device is also RoHS compliant, adhering to environmental standards that restrict the use of hazardous substances in electronic components.

In summary, the Texas Instruments TXS0104ED is a versatile, efficient, and reliable solution for voltage level translation in mixed-voltage digital systems. Its bidirectional channels, automatic direction sensing, and ESD protection make it an excellent choice for interfacing between devices with different voltage domains in a wide range of applications.
