Products specifications

Category Circuit Protection>TVS - Diodes
Mfr Texas Instruments
Package Tape & Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 14V (Max)
Voltage - Breakdown (Min) 16.2V
Voltage - Clamping (Max) @ Ipp 19.3V
Current - Peak Pulse (10/1000µs) 8A
Power - Peak Pulse 140W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 120pF @ 1MHz
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 6-WDFN Exposed Pad
Supplier Device Package 6-WSON (2x2)
Base Product Number TVS1400
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names 296-50511-6,TVS1400DRVR-ND,296-50511-1,296-50511-2
Standard Package 3,000
Win Source Part Number 960831-TVS1400DRVR
Ultra Librarian 3D Model Ultra Librarian TVS1400DRVR CAD Model

Description

The TVS1400DRVR is a state-of-the-art transient voltage suppression (TVS) diode device from Texas Instruments, designed to protect sensitive electronics from voltage spikes and surges that can occur due to sudden changes in power levels, lightning strikes, and other transient voltage events.

This robust component is capable of dissipating high transient energy and can clamp transient voltages to a safe level before they can damage your circuit. The TVS1400DRVR is particularly suited for applications where electronic devices are exposed to harsh electrical environments, including industrial, automotive, telecommunications, and consumer electronics.

Key Features:

  • Transient Protection: The TVS1400DRVR offers excellent transient voltage protection, ensuring the safety and reliability of the protected device.
  • Low Clamping Voltage: This device features a low clamping voltage, which reduces the stress on the protected component during a transient event.
  • High Surge Capability: With its high surge capability, the TVS1400DRVR can handle significant surge currents without degradation, ensuring long-term performance and durability.
  • Fast Response Time: The device reacts quickly to transient events, providing immediate protection to the circuit.
  • Compact Package: The TVS1400DRVR comes in a small-footprint package, making it ideal for space-constrained applications.

Applications:

  • Automotive systems
  • Industrial controls
  • Telecommunication infrastructure
  • Consumer electronics
  • Power supply protection

The TVS1400DRVR is designed to integrate seamlessly into various circuit designs, providing a reliable shield against voltage transients. Its performance and small size make it an excellent choice for designers looking to enhance the durability and reliability of their electronic products.

With Texas Instruments' commitment to quality and performance, you can trust the TVS1400DRVR to deliver consistent protection, ensuring the longevity and stability of your electronic applications.
