TUSB1210BRHBR USB 2.0 Transceiver - Texas Instruments

The TUSB1210BRHBR is a highly integrated Universal Serial Bus (USB) 2.0 transceiver chip produced by Texas Instruments. It serves as a bridge between a USB host or peripheral controller and the physical USB bus, providing a full-speed (12 Mbps), high-speed (480 Mbps), or low-speed (1.5 Mbps) interface as required. This versatile transceiver is an ideal solution for portable electronic devices, such as smartphones, tablets, and other consumer electronics that require USB connectivity.

Key Features:

• USB Interface: Compliant with USB 2.0 specification, the TUSB1210BRHBR supports high-speed (HS), full-speed (FS), and low-speed (LS) data rates.
• UTMI+ Interface: Features UTMI+ Level 3 (with the addition of a parallel interface) for versatile connection to USB controllers.
• Integrated PHY: Contains a built-in Physical Layer (PHY) transceiver, reducing the need for external components and simplifying design efforts.
• Otg Features: Supports USB On-The-Go (OTG) capabilities, allowing devices to switch between host and peripheral roles as necessary.
• Power Efficiency: Includes power-saving modes such as suspend, sleep, and a battery charging feature to enhance power management in portable devices.
• Package: Available in a compact 32-pin QFN package, the TUSB1210BRHBR is designed to save board space and is suitable for space-constrained applications.

Applications:

• Smartphones and Tablets
• Digital Cameras and Camcorders
• Portable Media Players
• GPS Devices
• Personal Digital Assistants (PDAs)
• Electronic Book Readers

The TUSB1210BRHBR transceiver is designed to meet the robust demands of modern portable electronics. It provides a reliable and efficient USB interface solution that integrates seamlessly into a variety of platforms and applications. Texas Instruments' commitment to quality ensures that the TUSB1210BRHBR delivers the performance and reliability expected from a leader in USB connectivity solutions.
