The TPS386040RGPR is a state-of-the-art voltage supervisor component designed and manufactured by Texas Instruments, a leader in the semiconductor industry. This advanced device is engineered to provide high-precision monitoring and reset functionality for four individual voltage rails, making it an ideal solution for multi-voltage systems. The TPS386040RGPR is housed in a compact QFN-20 package, allowing for space-efficient integration into a wide range of electronic applications.

Key Features

• Quad Voltage Monitoring: Equipped to supervise four voltage rails simultaneously, the TPS386040RGPR ensures that each voltage level remains within preset thresholds, enhancing system reliability.
• Adjustable Thresholds: The device allows for precise setting of undervoltage and overvoltage thresholds, providing customization to meet specific design requirements.
• Manual Reset: An additional feature includes a manual reset input, which enables users to initiate a system reset manually, offering greater control over system behavior.
• Low Quiescent Current: With its low quiescent current consumption, this voltage supervisor is optimized for power-sensitive applications, contributing to overall energy efficiency.
• Programmable Delay Time: The TPS386040RGPR offers programmable delay times for reset signals, allowing designers to tailor the timing to the needs of their system.

Applications

The versatility of the TPS386040RGPR makes it suitable for a diverse array of applications. It is particularly beneficial in systems where multiple supply voltages need to be monitored with precision, such as in industrial control units, automotive electronics, computing devices, and portable consumer electronics. Its robust feature set ensures that it can meet the stringent requirements of mission-critical systems, providing peace of mind through enhanced operational stability.

Quality and Support

Texas Instruments is known for its commitment to quality, and the TPS386040RGPR is no exception. It is built to meet high standards of performance and reliability. Additionally, Texas Instruments provides extensive technical support and resources, including datasheets, application notes, and design tools, to assist engineers in integrating this voltage supervisor into their designs with confidence.
