The TPS1H200AQDGNRQ1 is a robust automotive-grade power switch from Texas Instruments, designed to handle high-side power distribution in a compact and efficient manner. This advanced protection device is specifically engineered to meet the rigorous demands of automotive applications, providing both overcurrent and overvoltage protection for loads such as bulbs, solenoids, and motors.

Key Features

• Wide Operating Voltage: The device supports a broad range of input voltages from 3.5V to 40V, making it versatile for various automotive electrical systems.
• High Current Capability: It can handle continuous current up to 10A, suitable for powering a wide array of high-demand components.
• Thermal Shutdown Protection: With an integrated thermal shutdown feature, the TPS1H200AQDGNRQ1 prevents overheating, enhancing the longevity and reliability of both the switch and the system it protects.
• Adjustable Current Limit: The current limit can be set with an external resistor, providing flexibility in design and ensuring precise control over the power distribution.
• Status Flag Output: A diagnostic feedback is available through a status flag, informing the system about the switch's operational status and fault conditions.
• Reverse Battery Protection: The device is designed to be immune to damage when subjected to reverse battery connection, a critical feature for automotive power systems.

Applications

The TPS1H200AQDGNRQ1 is ideal for a variety of automotive applications, including but not limited to:

• Body Control Modules
• Automotive Lighting Systems
• Powertrain Systems
• Engine Control Units
• Infotainment Systems

Quality and Reliability

As an AEC-Q100 qualified device, the TPS1H200AQDGNRQ1 meets the stringent quality standards required for automotive electronics. It is housed in a compact 8-pin DGN package, optimized for space-constrained applications, and is specified for operation over a temperature range of -40°C to 150°C, ensuring performance in harsh automotive environments.
