Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Type Programmable Timer
Operating Supply Voltage 1.8 V ~ 5 V
Operating Supply Current 35nA
Operating Temperature Range -40°C ~ 105°C
Package SOT-23-6 Thin, TSOT-23-6
Manufacturer Package TSOT-23-6
Mounting SMD
Win Source Part Number 1272043-TPL5010DDCR
Manufacturer Homepage www.ti.com
Family Name TPL5010
Introduction Date January 16, 2015
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPL5010DDCR CAD Model

Description

Introducing the Texas Instruments TPL5010DDCR

The Texas Instruments TPL5010DDCR is a highly efficient, nano-power system timer that is perfect for extending the battery life of your applications. This sophisticated device is designed to provide the most reliable timing solutions for power-sensitive systems, making it an ideal choice for a wide array of electronic products.

At the heart of the TPL5010DDCR is its ability to consume extremely low power, with a typical current consumption of only 35 nA. This feature ensures that battery-powered applications such as wearables, wireless sensors, and other IoT devices can operate for extended periods without frequent battery replacements or recharges.

Key Features:

  • Ultra-Low Power Consumption: With a current draw of just 35 nA, the TPL5010DDCR is engineered to maximize battery life, making it perfect for energy-critical designs.
  • Programmable Time Intervals: Users can customize the timer intervals from 100 ms to 7200 s, providing versatility to match the specific timing requirements of different applications.
  • Watchdog Functionality: The device includes a built-in watchdog timer that helps to ensure system reliability by monitoring system operation and resetting the processor in case of a malfunction.
  • Manual Reset: A manual reset feature allows the user to reset the timer, offering additional control and safety for your system.
  • Small Package Size: The TPL5010DDCR comes in a tiny 6-pin SOT-23 package, making it suitable for space-constrained applications.

With its precision timing capabilities, the TPL5010DDCR can significantly reduce the overall power consumption of an application by waking up the system only when necessary. This functionality is crucial for modern, eco-friendly electronics that prioritize energy efficiency without compromising on performance.

Whether you are developing smart meters, home automation systems, or portable health devices, the TPL5010DDCR from Texas Instruments is a reliable choice to manage your power-critical tasks with ease. By integrating this timer into your design, you can achieve an optimal balance between functionality and power conservation, paving the way for innovative, long-lasting electronic products.
