Products specifications

Categories Circuit Protection
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 3V
Minimum Breakdown Voltage 6.1V
Power Dissipation - Pd 35W
Applications General Purpose
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package 5-SOT
Win Source Part Number 033553-TPD4E002DRLR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Imaging, Video & Vision, Consumer Electronics, Industrial
Ultra Librarian 3D Model Ultra Librarian TPD4E002DRLR CAD Model

Description

The TPD4E002DRLR from Texas Instruments is a state-of-the-art, low-capacitance electrostatic discharge (ESD) protection device designed to safeguard high-speed data lines from harmful ESD events. This compact, robust component is ideal for applications where board space is at a premium and high signal integrity is essential.

Key Features:

  • Low Clamping Voltage: Ensures that sensitive circuits are well-protected from ESD strikes, minimizing the risk of damage to the protected downstream components.
  • Low Capacitance: With a typical capacitance of just 0.8 pF per channel, the TPD4E002DRLR is particularly well-suited for high-speed interfaces, ensuring minimal signal distortion.
  • Multi-Channel Protection: The device features four ESD protection channels, making it an efficient solution for protecting multiple data lines with a single component.
  • Wide Operating Voltage Range: It operates over a wide voltage range, accommodating various applications and ensuring compatibility with numerous high-speed interfaces.
  • Robust ESD Protection: It can withstand ESD strikes of ±8 kV contact discharge and ±15 kV air-gap discharge, as per the IEC 61000-4-2 international standard, providing strong defense against common ESD events.
  • Space-Saving Package: The TPD4E002DRLR comes in a tiny SOT-6 package, allowing for high-density mounting and saving valuable PCB space.

Applications:

The device is versatile and can be used in a wide range of applications, including:

  • USB 1.1/2.0/3.0 Interfaces
  • HDMI, DisplayPort, and other high-speed data interfaces
  • Mobile Handsets, Portable Electronics
  • Serial ATA (SATA) and other high-speed data lines

Conclusion:

With its combination of low-capacitance, multi-channel protection, and a compact form factor, the TPD4E002DRLR is an excellent choice for designers looking to enhance the ESD resilience of their high-speed digital interfaces. Texas Instruments' commitment to quality ensures that this ESD protection device is reliable and effective in safeguarding sensitive electronic components against the potentially damaging effects of electrostatic discharge.
