Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5.5V (Max)
Minimum Breakdown Voltage 11V
Power Dissipation - Pd 100W
Power Line Protection Yes
Applications Ethernet
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 6-SOT
Win Source Part Number 033552-TPD4E001DRLR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Power Management, Imaging, Video & Vision, Metering, Medical, Industrial
Ultra Librarian 3D Model Ultra Librarian TPD4E001DRLR CAD Model

Description

Overview of Texas Instruments TPD4E001DRLR

The TPD4E001DRLR is a robust transient voltage suppression (TVS) device from Texas Instruments, designed to protect sensitive electronics from electrostatic discharge (ESD) and other voltage-induced transient events. This compact component, housed in a small 6-pin SOT (DRL) package, is an ideal solution for safeguarding high-speed data lines and general-purpose I/O interfaces in a variety of applications.

Key Features

  • ESD Protection: The TPD4E001DRLR offers excellent ESD protection for electronic equipment, meeting IEC 61000-4-2 (ESD) ±8-kV (contact), ±15-kV (air) standards, ensuring devices are shielded from the most common electrostatic events.
  • Low Capacitance: With a low loading capacitance of 0.8 pF (typical) per channel, it is particularly suitable for protecting high-speed data lines without significantly affecting signal integrity.
  • Multi-Channel Integration: This device integrates four ESD clamping circuits, allowing it to protect up to four lines simultaneously, making it a space-efficient choice for compact electronic designs.
  • Low Leakage Current: It features a low leakage current of less than 1 nA (max), which helps in reducing power consumption and preserving battery life in portable applications.
  • Versatility: The TPD4E001DRLR is versatile and can be used in a wide range of applications, including USB interfaces, HDMI, Ethernet, and other vulnerable high-speed ports.

Applications

The TPD4E001DRLR is suitable for protecting a variety of electronic devices, including:

  • Smartphones, Tablets, and Portable Electronics
  • Laptops, Desktops, and Servers
  • Digital Cameras and Audio/Video Equipment
  • Set-Top Boxes and Digital TVs
  • Networking Equipment and Routers

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the TPD4E001DRLR is no exception. It is manufactured to high standards, ensuring that it delivers consistent performance and durability in the most demanding environments.

Conclusion

The TPD4E001DRLR from Texas Instruments is a highly effective solution for protecting sensitive electronic circuits from the damaging effects of ESD and other transient voltage events. Its low capacitance, multi-channel protection, and small form factor make it an excellent choice for designers looking to enhance the durability and reliability of their products without compromising on space or signal quality.
