The TPD2E009DRTR is a state-of-the-art transient voltage suppressor (TVS) diode array designed by Texas Instruments to provide a high level of protection for sensitive electronic components. This compact and versatile device is engineered to protect two data or transmission lines from the damaging effects of Electrostatic Discharge (ESD), Electrical Fast Transients (EFT), and lightning-induced surge events.

Key Features

• ESD Protection: The TPD2E009DRTR offers exceptional ESD protection of ±8kV contact discharge and ±15kV air-gap discharge, as per the IEC 61000-4-2 international standard.
• Low Capacitance: With a low loading capacitance of 0.8 pF (typical), it is ideal for use in high-speed data interfaces without significantly affecting signal integrity.
• Low Leakage Current: It has an ultra-low leakage current of 1 nA (max), making it suitable for power-sensitive applications.
• Small Package Size: The device comes in a small SOT-23 (DRTR) package, which is perfect for space-constrained applications.
• RoHS Compliant: It is compliant with RoHS standards, ensuring that it meets the environmental and safety standards set for electronic components.

Applications

The TPD2E009DRTR is designed for use in a wide range of applications where data line protection is critical. It is commonly used in:

• USB Interfaces
• HDMI Ports
• Portable Electronics
• Notebooks, Desktops, and Servers
• Mobile Phones
• Network Ports
• Other High-Speed Data Interfaces

Why Choose TPD2E009DRTR?

Choosing the TPD2E009DRTR for your circuit protection needs means opting for a device that provides robust protection without compromising on performance. Its combination of low capacitance, high ESD protection, and small form factor makes it an excellent choice for safeguarding high-speed data lines in today's compact and sophisticated electronic devices.

With Texas Instruments' reputation for quality and reliability, the TPD2E009DRTR is a component that engineers and designers can trust to protect their valuable electronic systems against transient voltage spikes and surges.
