Product Overview: TLV1117-18CDCY

The TLV1117-18CDCY is a high-performance, low-dropout linear regulator designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This regulator is specifically engineered to deliver a fixed output voltage of 1.8V with a maximum output current of 800mA, making it an ideal choice for a wide range of applications that require a stable and reliable power supply.

Key Features

• Output Voltage: The device provides a precise 1.8V output, which is critical for powering sensitive electronic circuits that require a stable voltage level.
• High Output Current: With the capability to deliver up to 800mA of output current, the TLV1117-18CDCY can easily power a variety of components, including microcontrollers, sensors, and RF devices.
• Low Dropout Voltage: The low dropout (LDO) feature ensures efficient operation even when the input voltage is very close to the output voltage, which helps in reducing power loss and improving system efficiency.
• Thermal Protection: The device includes built-in thermal shutdown protection that safeguards it from overheating, thereby enhancing its reliability and longevity.
• Current Limit Protection: The TLV1117-18CDCY also features current limit protection to prevent damage from overcurrent conditions.
• Wide Input Voltage Range: It supports a broad input voltage range, accommodating various power supply scenarios and ensuring flexibility in system design.
• Package: The regulator is available in a compact SOT-223 package, which is suitable for space-constrained applications.

Applications

The TLV1117-18CDCY is versatile and can be used in a multitude of electronic devices and systems. It is particularly well-suited for portable and battery-powered applications due to its low power consumption. Common applications include:

• Consumer Electronics
• Handheld Devices
• Embedded Systems
• Power Management Circuits
• Point-of-Load Applications

Quality and Reliability

As with all Texas Instruments products, the TLV1117-18CDCY is designed to meet high standards of quality and reliability. TI's commitment to excellence ensures that this LDO regulator delivers consistent performance and robust operation in diverse conditions.

For designers and engineers looking for a dependable power solution, the TLV1117-18CDCY from Texas Instruments offers an optimal blend of features, efficiency, and reliability, making it an excellent choice for a wide array of power supply requirements.
