The SN75176BDRG4 is a differential bus transceiver from Texas Instruments, a leading global semiconductor manufacturer known for its high-quality products. It is designed to meet the requirements of ANSI Standards EIA/TIA-422-B and ITU Recommendation V.11 and is particularly suitable for high-speed bidirectional communication on multipoint bus transmission lines.

It consists of a differential line driver and a differential line receiver, both of which operate from a single 5V power supply. The driver and receiver have active-high and active-low enables, respectively, which can be externally connected together to function as direction control. The driver differential outputs and the receiver differential inputs are connected internally to form differential input/output (I/O) bus ports that are designed to offer minimum loading to the bus whenever the driver is disabled or VCC = 0. This feature makes the SN75176BDRG4 particularly suitable for party-line (bus-structured) applications.

The SN75176BDRG4 is characterized for operation from 0°C to 70°C and is available in an 8-pin SOIC package. It features a wide common-mode voltage range, making it ideal for multipoint applications over long cable runs.

Key features of the SN75176BDRG4 include its ability to operate from a single 5V supply, differential line operation for improved noise immunity, and its meets or exceeds the requirements of ANSI TIA/EIA-422-B, ITU recommendation V.11 and ISO 8482:1987(E). It also offers a wide common-mode range: -7V to 12V and thermal shutdown protection.

The SN75176BDRG4 is a reliable, high-performance solution for a range of applications including telecommunications, industrial networks, control systems, and more. Trust Texas Instruments for superior quality and performance in all your semiconductor needs.
