SN74LVC1G32QDCKRQ1 - Texas Instruments Single 2-Input Positive-OR Gate

The SN74LVC1G32QDCKRQ1 is a high-performance, single 2-input positive-OR gate designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This integrated circuit is part of the LVC family, which is known for low-voltage CMOS logic that operates at a voltage range of 1.65 to 5.5V. This makes the device suitable for interfacing with 5V and 3.3V systems, providing design flexibility for mixed-voltage applications.

This OR gate IC is optimized for automotive and other applications requiring stringent quality standards, as indicated by the 'Q1' suffix in its product name. It meets or exceeds the requirements of the automotive industry standards, ensuring reliability and performance under extreme conditions.

The SN74LVC1G32QDCKRQ1 features a wide operating temperature range, typically from -40°C to +125°C, making it robust for automotive environments. Its SC70 (SOT-323) package is compact and space-efficient, ideal for high-density integration in modern electronic systems.

With its low power consumption and high-speed operation, this OR gate is an excellent choice for power-sensitive and timing-critical applications. The device also supports 5V tolerant inputs, which allows for direct interfacing with TTL levels, further enhancing its versatility.

Key specifications of the SN74LVC1G32QDCKRQ1 include:

• Logic Family: LVC
• Logic Type: 2-Input Positive-OR Gate
• Operating Voltage Range: 1.65V to 5.5V
• Input Voltage Level: 5V Tolerant
• Output Current: ±32 mA
• Propagation Delay Time: 3.4 ns (max) at 3.3V
• Operating Temperature Range: -40°C to +125°C
• Mounting Type: Surface Mount
• Package / Case: SC70-6 (SOT-323-6)

Whether you're designing automotive electronics, consumer devices, or industrial systems, the SN74LVC1G32QDCKRQ1 from Texas Instruments offers the performance and reliability needed for your logic operations.
