SN74HC14DR

Name: SN74HC14DR
Brand: Texas Instruments
SKU: 333529
Availability: InStock
Rating: 4.85 (1320 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SN74HC14DR
Manufacturer	Texas Instruments
Catalog	Logic - Gates and Inverters
Description	IC HEX SCHMITT-TRIG INV 14-SOIC
Datasheet	SN74HC14DR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Features	Schmitt Trigger
Supply Voltage - Operating	2 V to 6 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	5.2mA, 5.2mA
Logic Level - Low	0.3 V to 1.2 V
Logic Level - High	1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL	21ns @ 6V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	14-SOIC
Dimension	14-SOIC (0.154", 3.90mm Width)
Win Source Part Number	006831-SN74HC14DR
Family Name	SN74HC14
Introduction Date	July 01, 2011
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2027
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial
Ultra Librarian 3D Model	Ultra Librarian SN74HC14DR CAD Model

Alternative Products

Description

The SN74HC14DR is an advanced high-speed complementary metal oxide semiconductor (CMOS) device manufactured by Texas Instruments, a renowned global semiconductor company.

Function: Six independent Schmitt-trigger inverters
Voltage Range: 2V to 6V
Noise Immunity: 1V
Package: small outline integrated circuit (SOIC) package with 14 pins
Operating Temperature Range: from -40°C to 85°C
Current Drive Capability: 4 mA @ 5V
Compliance: RoHS compliant
