SN74HC14APWR Real Image SN74HC14APWR Real Image
Same model may have multiple batches, images only for reference.
SN74HC14APWR Real Image SN74HC14APWR Real Image
SN74HC14APWR Real Image SN74HC14APWR Real Image
Same model may have multiple batches, images only for reference.

SN74HC14APWR

Part No SN74HC14APWR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC HEX SCHMITT-TRIG INV 14TSSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Features Schmitt Trigger
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.3 V to 1.2 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 19ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-TSSOP
Dimension 14-TSSOP (0.173", 4.40mm Width)
Win Source Part Number 082298-SN74HC14APWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian SN74HC14APWR CAD Model

Description

The SN74HC14APWR is a high-performance integrated circuit (IC) product from Texas Instruments, a renowned global semiconductor company known for its innovative technology and high-quality products.

  • Technology: CMOS technology
  • Voltage Range: 2V to 6V
  • Package: TSSOP (Thin Shrink Small-Outline Package) with 14 pins
  • Compliance: RoHS compliant
  • Typical Propagation Delay Time: 15 ns
  • Fan-Out: Capable of driving up to 10 Low Power Schottky loads
