SN74HC04DR Real Image SN74HC04DR Real Image1 SN74HC04DR Real Image2
Same model may have multiple batches, images only for reference.
SN74HC04DR Real Image SN74HC04DR Real Image1 SN74HC04DR Real Image2
SN74HC04DR Real Image SN74HC04DR Real Image1 SN74HC04DR Real Image2
Same model may have multiple batches, images only for reference.

SN74HC04DR

Part No SN74HC04DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC HEX INVERTER 14-SOIC
Datasheet
SN74HC04DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.5 V to 1.8 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 16ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 006798-SN74HC04DR
Family Name SN74HC04
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Consumer Electronics, Communications & Networking, Metering
Ultra Librarian 3D Model Ultra Librarian SN74HC04DR CAD Model

Description

The SN74HC04DR is a high-performance, advanced CMOS digital logic device from Texas Instruments, a global semiconductor design and manufacturing company renowned for its high-quality products.

  • Series: 74HC04
  • Device Type: Hex Inverter chip
  • Boolean Function: Y = A
  • Technology: Silicon gate CMOS
  • Load Drive: 10 LS-TTL loads
  • Voltage Range: 2V to 6V
  • Operating Temperature Range: -40°C to 85°C
  • Package: SOIC-14
  • RoHS Compliant: Yes
  • JEDEC Standards: Complies with JEDEC standards
