SN74AHC1G08QDCKRQ1 Real Image SN74AHC1G08QDCKRQ1 real image5866 SN74AHC1G08QDCKRQ1 real image5867 SN74AHC1G08QDCKRQ1 Real Image1 SN74AHC1G08QDCKRQ1 Real Image2 SN74AHC1G08QDCKRQ1 Real Image3
Same model may have multiple batches, images only for reference.
SN74AHC1G08QDCKRQ1 Real Image SN74AHC1G08QDCKRQ1 real image5866 SN74AHC1G08QDCKRQ1 real image5867 SN74AHC1G08QDCKRQ1 Real Image1 SN74AHC1G08QDCKRQ1 Real Image2 SN74AHC1G08QDCKRQ1 Real Image3
SN74AHC1G08QDCKRQ1 Real Image SN74AHC1G08QDCKRQ1 real image5866 SN74AHC1G08QDCKRQ1 real image5867 SN74AHC1G08QDCKRQ1 Real Image1 SN74AHC1G08QDCKRQ1 Real Image2 SN74AHC1G08QDCKRQ1 Real Image3
Same model may have multiple batches, images only for reference.

SN74AHC1G08QDCKRQ1

Part No SN74AHC1G08QDCKRQ1
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE AND 1CH 2-INP SC-70-5
Datasheet
SN74AHC1G08QDCKRQ1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 2 V to 5.5 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 8mA, 8mA
Logic Level - Low 0.5 V to 1.65 V
Logic Level - High 1.5 V to 3.85 V
Max Propagation Delay @ V, Max CL 7.9ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 065181-SN74AHC1G08QDCKRQ1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SN74AHC1G08
Introduction Date September 15, 2011
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian SN74AHC1G08QDCKRQ1 CAD Model

Description

The SN74AHC1G08QDCKRQ1 is a high-performance, automotive qualified single 2-input positive-AND gate from Texas Instruments, a renowned global semiconductor company.

  • Voltage Range: 2V to 5.5V
  • Operating Temperature: -40°C to 125°C
  • Input Current: 1 µA
  • Schmitt-trigger: Action at all inputs
  • Package: Small SC70-5 package
  • Drive Capability: Up to 8 mA @ 4.5V
  • Output Transitions: Glitch-free
  • Qualification: AEC-Q100 qualified
