REF1004C-2.5 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Reference Type Shunt
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 2.5V
Output Current 20mA
Tolerance ±0.4%
Temperature Coefficient 20ppm/°C Typical
Noise - 10Hz to 10kHz 120μVrms
Current - Cathode 20μA
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 027278-REF1004C-2.5
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 75
Ultra Librarian 3D Model Ultra Librarian REF1004C-2.5 CAD Model

Description

Product REF1004C-2.5 is a high precision voltage reference from Texas Instruments, a globally recognized leader in the electronics industry.

  • Output: Fixed 2.5-volt output
  • Initial Accuracy: 0.2%
  • Drift: 50ppm/°C
  • Dropout Voltage: Low
  • Quiescent Current: Low
  • Line and Load Regulation: Excellent
  • Short-Circuit Protection: Yes
  • Thermal Shutdown Capability: Yes
  • Package: Small-outline transistor (SOT) package
