PTH08080WAH

Name: PTH08080WAH
Brand: Texas Instruments
SKU: 283836
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PTH08080WAH
Manufacturer	Texas Instruments
Catalog	Power Supplies Board Mount DCDC Converters
Description	MODULE PIP .9-5.5V 2.25A HORZ TH
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Texas Instruments
Standard Package	90
Category	Power Supplies - Board Mount
Family	DC DC Converters
Series	PTH08080W
Packaging	Tray
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	4.5V
Voltage - Input (Max)	18V
Voltage - Output 1	0.9 ~ 5.5 V
Current - Output (Max)	2.25A
Applications	ITE (Commercial)
Mounting Style	Through Hole
Package	5-DIP Module
Size / Dimension	0.60" L x 0.50" W x 0.32" H (15.2mm x 12.7mm x 8.1mm)
Operating Temperature Range	-40°C ~ 85°C
Efficiency	93.5%
Power (Watts) - Max	12.4W
Catalog	PTH08080W Series
Win Source Part Number	086074-PTH08080WAH
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Communications & Networking, Sensing & Instrumentation
Ultra Librarian 3D Model	Ultra Librarian PTH08080WAH CAD Model

Alternative Products

Description

The PTH08080WAH is an advanced, high-performance power module from Texas Instruments, a leading global semiconductor company.

Output Current: 2.25-A
Input Voltage: 5.5-V
Input Voltage Range: 4.5 V to 5.5 V
Output Voltage: Adjustable, 0.9 V to 3.6 V
Efficiency: Up to 96%
Size: 10.4 mm by 9.1 mm by 2.6 mm
Over-Current Protection: Yes
Over-Temperature Protection: Yes
Auto-Track Sequencing: Yes
Pre-Bias Start-Up: Yes
RoHS Compliant: Yes
Operating Temperatures: -40°C to 85°C
