PTH05000WAH

Name: PTH05000WAH
Brand: Texas Instruments
SKU: 283812
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PTH05000WAH
Manufacturer	Texas Instruments
Catalog	Power Supplies Board Mount DCDC Converters
Description	MODULE PIP 5VIN 6A HORZ T/H
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Texas Instruments
Standard Package	56
Category	Power Supplies - Board Mount
Family	DC DC Converters
Series	PTH05000W
Packaging	Tray
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	4.5V
Voltage - Input (Max)	5.5V
Voltage - Output 1	0.9 ~ 3.6 V
Current - Output (Max)	6A
Applications	ITE (Commercial)
Mounting Style	Through Hole
Package	5-DIP Module
Size / Dimension	0.75" L x 0.50" W x 0.34" H (19.1mm x 12.7mm x 8.6mm)
Operating Temperature Range	-40°C ~ 85°C
Efficiency	92%
Power (Watts) - Max	21.6W
Catalog	PTH05000W Series
Win Source Part Number	085717-PTH05000WAH
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian PTH05000WAH CAD Model

Alternative Products

Description

The PTH05000WAH is a highly sophisticated, non-isolated power module from Texas Instruments, a global leader in semiconductor technology.

Input Voltage Range: 5V to 14V
Adjustable Output Voltage: 0.8V to 5.5V
Auto-Track Sequencing: Yes
Under-Voltage Lockout: Yes
Output Over-Current Protection: Yes
Over-Temperature Shutdown: Yes
High Efficiency: Up to 96%
