MAX3232EIDWR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 021519-MAX3232EIDWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3232EIDWR CAD Model

Description

The MAX3232EIDWR from Texas Instruments is a high-performance, dual receiver/dual transmitter RS-232 interface device.

  • Frequency: Up to 120 kbps
  • VCC Supply Voltage: 3.0V to 5.5V
  • Auto-Power-Down: Yes
  • Auto-Power-Down Activation: 30 seconds of inactivity
  • Receivers: 2, up to ±30V input
  • Transmitters: 2, output from ±5.5V to ±7V
  • Receiver Input Impedance: 3kΩ
  • ESD Protection (HBM): ±15kV
  • ESD Protection (CDM): ±8kV
  • Package: 16-SOIC (0.295", 7.50mm Width)
  • Operating Temperature: -40°C to 85°C
