Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 082984-MAX3232ECPW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3232ECPW CAD Model

Description

The MAX3232ECPW is a top-tier product from the globally acclaimed manufacturer, Texas Instruments.

  • Description: Dual driver/receiver with capacitive voltage generator
  • Function: Converts TIA/EIA-232-F inputs to 5-V TTL/CMOS levels and TTL/CMOS input levels into TIA/EIA-232-F levels.
  • Receivers Threshold: Typical threshold of 1.3 V
  • Receivers Hysteresis: Typical hysteresis of 0.5 V
  • Receivers Input: Can accept ±30-V inputs
  • Data Signaling Rate: Up to 250 kbit/s
  • ESD Protection: Up to ±15-kV ESD (Electrostatic Discharge)
  • Operating Voltage: Single 5-V power supply
  • Package: 20-pin TSSOP (Thin Shrink Small Outline Package)
  • Application: Battery-powered systems, PDAs, laptops, and other mobile computing applications
  • Feature: Automatic power-down
