LMZ14203TZX-ADJ/NOPB Real Image LMZ14203TZX-ADJ/NOPB real image LMZ14203TZX-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.
LMZ14203TZX-ADJ/NOPB Real Image LMZ14203TZX-ADJ/NOPB real image LMZ14203TZX-ADJ/NOPB Real Image
LMZ14203TZX-ADJ/NOPB Real Image LMZ14203TZX-ADJ/NOPB real image LMZ14203TZX-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.

LMZ14203TZX-ADJ/NOPB

Part No LMZ14203TZX-ADJ/NOPB
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC BUCK SYNC ADJ 3A TO-PMOD-7
Datasheet
LMZ14203TZX-ADJ/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series SIMPLE SWITCHER?
Packaging Reel(TR)
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 6V
Voltage - Input (Max) 42V
Voltage - Output 1 0.8 ~ 6 V
Current - Output (Max) 3A
Applications ITE (Commercial)
Features UVLO
Mounting Style SMD/SMT
Package TO-PMOD-7, Power Module
Size / Dimension 0.40" L x 0.39" W x 0.18" H (10.2mm x 9.9mm x 4.6mm)
Operating Temperature Range -40°C ~ 125°C
Efficiency 90%
Power (Watts) - Max 18W
Win Source Part Number 124554-LMZ14203TZX-ADJ/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LMZ14203TZX-ADJ/NOPB CAD Model

Description

The is a high-performance and easy-to-use power module that combines a 3A DC/DC converter with a shielded inductor and passives in a compact QFN package from Texas Instruments.

  • Output Voltage Range: 0.8V to 6V
  • Input Voltage Range: 6V to 42V
  • Features: High efficiency, adjustable switching frequency, thermal and overcurrent protection, adjustable soft-start
  • Package Size: 10.16mm x 13.77mm x 4.57mm
  • Applications: Telecommunications, industrial, and home appliances
  • Protection Features: Over-temperature, under-voltage lockout, and over-current protection
