LMZ14203TZ-ADJ/NOPB Real Image LMZ14203TZ-ADJ/NOPB real image LMZ14203TZ-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.
LMZ14203TZ-ADJ/NOPB Real Image LMZ14203TZ-ADJ/NOPB real image LMZ14203TZ-ADJ/NOPB Real Image
LMZ14203TZ-ADJ/NOPB Real Image LMZ14203TZ-ADJ/NOPB real image LMZ14203TZ-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.

LMZ14203TZ-ADJ/NOPB

Part No LMZ14203TZ-ADJ/NOPB
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC BUCK SYNC ADJ 3A TO-PMOD-7 / Module DC-DC 1-OUT 0.8V to 6V 3A 7-Pin TO-PMOD EP T/R
Datasheet
LMZ14203TZ-ADJ/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series SIMPLE SWITCHER
Packaging Reel(TR)
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 6V
Voltage - Input (Max) 42V
Voltage - Output 1 0.8 ~ 6 V
Current - Output (Max) 3A
Applications ITE (Commercial)
Features UVLO
Mounting Style SMD/SMT
Package TO-PMOD-7, Power Module
Size / Dimension 0.40" L x 0.39" W x 0.18" H (10.2mm x 9.9mm x 4.6mm)
Operating Temperature Range -40°C ~ 125°C
Efficiency 90%
Power (Watts) - Max 18W
Win Source Part Number 019692-LMZ14203TZ-ADJ/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing, Consumer Electronics, Security, Communications & Networking, Imaging, Video & Vision, Defence, Military & Aerospace, Motor Drive & Control, Avionics
Family Name LMZ14203
Introduction Date January 15, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LMZ14203TZ-ADJ/NOPB CAD Model

Description

The is a high-performing, easy-to-use power module from Texas Instruments. It is a DC/DC converter module that integrates a 3A converter with a shielded inductor and passives into a low-profile, QFN package.

  • Output Voltage Range: 0.8V to 6V
  • Input Voltage Range: 6V to 42V
  • Protection Features: Thermal shutdown, under-voltage lockout, over-current protection
  • Package Size: 10.16mm x 13.77mm x 4.57mm
  • Applications: Telecommunications equipment, industrial equipment, home appliances
