The LMH0387SL/NOPB is a cutting-edge 3G/HD/SD SDI Configurable I/O Adaptive Cable Equalizer developed by Texas Instruments. This high-performance integrated circuit is designed to provide unparalleled signal conditioning for serial digital interface (SDI) signals in professional video and broadcast applications. Its advanced features and robust design make it a go-to solution for a wide range of video processing needs.

Key Features

• Adaptive Cable Equalization: The LMH0387SL/NOPB offers superior equalization capabilities, automatically compensating for signal loss across long cable runs, ensuring clear and reliable video signals over distances of up to 140m at 3G-SDI, 200m at HD-SDI, and 400m at SD-SDI.
• Wide Data Rate Range: This device supports a broad spectrum of data rates from 143 Mbps to 2.97 Gbps, making it versatile enough to handle various SDI standards, including SMPTE 424M, SMPTE 292M, and SMPTE 259M-C.
• Low Power Consumption: Designed with efficiency in mind, the LMH0387SL/NOPB maintains low power consumption, which is critical in high-density video processing applications and helps reduce the overall system power budget.
• Integrated Reclocker: The on-chip reclocker provides jitter cleaning for the incoming signal, ensuring a stable and clean output, which is essential for maintaining signal integrity in digital video systems.
• Programmable Outputs: Users can program the outputs for either differential or single-ended modes, offering flexibility in interfacing with other components within the system.

Applications

• Professional Video Cameras
• Video Switchers
• Video Routers
• Broadcast Video Equipment
• Digital Signage

The LMH0387SL/NOPB comes in a compact 16-pin WQFN package and is characterized for operation over the free-air temperature range of -40°C to +85°C. Its robust design and advanced features ensure that it can meet the rigorous demands of professional video and broadcast environments, making it an essential component for any high-definition video application.
