LM393ADR Texas Instruments
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type General Purpose
Number of Elements 2
Output Type CMOS, MOS, Open-Collector, TTL
Supply Voltage - Operating 2 V to 36 V, ±1 V to 18 V
Voltage - Input Offset (Max) 2mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 20mA
Current - Quiescent (Max) 2.5mA
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 019210-LM393ADR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LM393A
Introduction Date June 01, 2010
ECCN EAR99
Country of Origin Malaysia, Mexico
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LM393ADR CAD Model

Description

The LM393ADR is a high-quality, low-power voltage comparator from Texas Instruments, a leading global semiconductor company.

  • Type: Dual differential comparator
  • Power Supply: Single power supply over a wide range of voltages
  • Gain: High gain
  • Bandwidth: Wide bandwidth
  • Differential Input Voltage Range: Equal to the power supply voltage
  • Supply Current Drain: Low
  • Output Saturation Voltage: Low
  • Package: Compact SOIC package
  • Compliance: RoHS compliant
  • Applications: Limit comparators, simple analog-to-digital converters, pulse, squarewave, and time delay generators, wide range VCO, MOS clock timers, multivibrators, and high voltage digital logic gates
