LM3549SQEV/NOPB

Part No LM3549SQEV/NOPB
Manufacturer Texas Instruments
Catalog Board Mount LED Drivers
Description BOARD EVAL LM3549 / LM3549 LED Driver Evaluation Board
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Texas Instruments
Output Current per Channel 700mA
Outputs and Type 1, Non-Isolated
Supplied Contents Board(s)
Utilized IC / Part LM3549
Win Source Part Number 778976-LM3549SQEV/NOPB
Popularity Medium
Supply and Demand Status Sufficient
Family Name LM3549
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM3549SQEV/NOPB CAD Model

Description

The LM3549SQEV/NOPB is a high-performance LED driver solution crafted by Texas Instruments, designed to efficiently manage power for LED backlighting in portable devices. This product is particularly well-suited for small-form-factor applications such as smartphones, tablets, and other handheld devices where space is at a premium and efficient power management is crucial.

Key Features

  • Integrated Boost Converter: The LM3549SQEV/NOPB includes an integrated boost converter that is capable of driving up to 10 LEDs in series, ensuring consistent brightness and enhancing display quality.
  • High Efficiency: With an efficiency rating that can reach up to 90%, this LED driver minimizes power consumption, thereby extending battery life in portable devices.
  • Adjustable Brightness: The device features an I2C-compatible interface that allows for precise control over LED brightness, enabling user-adjustable settings for various lighting conditions.
  • Compact Design: The LM3549SQEV/NOPB comes in a compact WQFN-24 package, making it an ideal choice for space-constrained applications.
  • Protection Features: It includes built-in open LED and over-temperature protection, safeguarding the device and the LEDs from potential damage.

Applications

The versatile nature of the LM3549SQEV/NOPB makes it suitable for a wide range of applications, particularly where efficient power management and space savings are critical. These applications include:

  • Smartphone and Tablet Backlighting
  • Portable Media Players
  • Handheld GPS Units
  • Other Battery-Operated Devices

Additional Information

The LM3549SQEV/NOPB is part of Texas Instruments' commitment to providing innovative, energy-efficient power solutions to meet the evolving needs of modern electronics. With its robust feature set and compact form factor, this LED driver stands out as a superior choice for manufacturers looking to enhance their products with reliable and efficient backlighting capabilities.
