LM1205N

Part No LM1205N
Manufacturer Texas Instruments
Catalog HOT - SALES and EOL Components (L)
Description 130 MHz/85 MHz RGB Video Amplifier System with Blanking
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Win Source Part Number 81155-LM1205N
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM1205N CAD Model

Description

The LM1205N is a high-performance, technologically-advanced product manufactured by Texas Instruments, a renowned global semiconductor company that designs, manufactures, tests, and sells analog and embedded processing chips.

  • Type: RGB Video Amplifier System with OSD
  • Amplifiers: Three matched video amplifiers with a bandwidth of 110 MHz
  • Feature: OSD (On-Screen Display)
  • Supply Voltages: Operates over a wide range of supply voltages, from 9V to 12V
  • Slew Rate: High slew rate of 1000V/µs
  • Operating Temperature Range: 0°C to 70°C
  • Package: 20-pin DIP package
