Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 3/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002066-ISO7241CDW
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian ISO7241CDW CAD Model

Description

The ISO7241CDW is a high-performance, quad-channel digital isolator product from Texas Instruments, a renowned global semiconductor company that designs and manufactures analog ICs and embedded processors.

  • Isolation Voltage: 2500 Vrms for 1 minute per UL1577
  • Channels: Four channels with two forward and two reverse-direction channels
  • Data Rate: Up to 25 Mbps
  • Power Consumption: Low
  • Supply Range: 3.0 V to 5.5 V
  • Temperature Range: -40°C to +125°C
  • Package: 16-pin SOIC (DW) package
  • Fail-Safe Output: Yes
