ISO7221ADRG4 Real Image ISO7221ADRG4 label picture ISO7221ADRG4 real image ISO7221ADRG4 real image566
Same model may have multiple batches, images only for reference.
ISO7221ADRG4 Real Image ISO7221ADRG4 label picture ISO7221ADRG4 real image ISO7221ADRG4 real image566
ISO7221ADRG4 Real Image ISO7221ADRG4 label picture ISO7221ADRG4 real image ISO7221ADRG4 real image566
Same model may have multiple batches, images only for reference.

ISO7221ADRG4

Part No ISO7221ADRG4
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 8SOIC
Datasheet
ISO7221ADRG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 1/1
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 1Mbps
Propagation Delay tpLH / tpHL (Max) 475ns, 475ns
Pulse Width Distortion (Max) 14ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 082545-ISO7221ADRG4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Automation & Process Control, Sensing & Instrumentation, Industrial
Ultra Librarian 3D Model Ultra Librarian ISO7221ADRG4 CAD Model

Description

The ISO7221ADRG4 from Texas Instruments is a high-performance, dual-channel digital isolator that offers a robust communication interface solution for a wide range of applications.

  • Channels: Two isolated channels
  • Data Rate: Up to 1 Mbps
  • Supply Voltage Range: 2.7V to 5.5V
  • Isolation Voltage: Up to 2500 Vrms for 1 minute per UL 1577
  • Power Consumption: Less than 2 mA of current per channel @ 1 Mbps
  • Package: Compact 8-pin SOIC package
