ISO7220CDR Real Image ISO7220CDR real image560 ISO7220CDR Real Image1 ISO7220CDR Real Image2 ISO7220CDR Real Image3 ISO7220CDR Real Image4 ISO7220CDR Real Image5 ISO7220CDR Real Image6
Same model may have multiple batches, images only for reference.
ISO7220CDR Real Image ISO7220CDR real image560 ISO7220CDR Real Image1 ISO7220CDR Real Image2 ISO7220CDR Real Image3 ISO7220CDR Real Image4 ISO7220CDR Real Image5 ISO7220CDR Real Image6
ISO7220CDR Real Image ISO7220CDR real image560 ISO7220CDR Real Image1 ISO7220CDR Real Image2 ISO7220CDR Real Image3 ISO7220CDR Real Image4 ISO7220CDR Real Image5 ISO7220CDR Real Image6
Same model may have multiple batches, images only for reference.

ISO7220CDR

Part No ISO7220CDR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description Digital Isolator CMOS 2-CH 25Mbps 8-Pin SOIC T/R / DGTL ISO 2.5KV GEN PURP 8SOIC
Datasheet
ISO7220CDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 2.8 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002044-ISO7220CDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name ISO7220C
Introduction Date May 01, 2007
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ISO7220CDR CAD Model

Description

The ISO7220CDR is a high-performance, dual-channel digital isolator product manufactured by Texas Instruments.

  • Channels: Two isolation channels
  • Data Rate: Up to 1 Mbps
  • Isolation Technology: Silicon dioxide (SiO2)
  • Withstand Voltage: Up to 2500 Vrms for one minute per UL 1577
  • Temperature Range: -40°C to +125°C
  • Package: Compact, surface-mount SOIC
