DRV5013BCQLPG - Hall Effect Sensor

The DRV5013BCQLPG is a digital latch Hall effect sensor designed and manufactured by Texas Instruments. This device offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features. The DRV5013BCQLPG is particularly suitable for industrial and automotive applications where reliable and durable magnetic sensing is a critical requirement.

Key Features

• Bipolar Latching Operation: The sensor exhibits a latching behavior, where it will maintain its state when the magnetic field is removed and will only change state when a magnetic field of opposite polarity is applied.
• Wide Operating Voltage Range: The device supports a supply voltage range from 2.5V to 38V, making it versatile for various applications and ensuring it can cope with supply fluctuations.
• High-Temperature Performance: It operates within a temperature range of -40°C to 125°C, ensuring consistent performance across a wide range of environmental conditions.
• Robust Protection Features: The DRV5013BCQLPG comes with built-in reverse supply protection up to -22V, and it is also capable of withstanding transient voltages up to 40V, providing excellent resilience in harsh electrical environments.
• Chopper-Stabilized Design: This design technique helps to reduce the sensor's sensitivity to physical and thermal stresses, enhancing the accuracy and stability of the magnetic sensing.

Applications

The versatility and robustness of the DRV5013BCQLPG make it an ideal choice for a wide array of applications, including:

• Position and speed sensing in industrial and automotive systems
• Motor control in brushless DC (BLDC) motors
• Open and close detection in consumer electronics
• Flow meters in utility meters

Package and Quality

The DRV5013BCQLPG is available in a small, low-profile SOT-23 package, which is suitable for space-constrained applications. Texas Instruments ensures high-quality standards, and the device is compliant with the AEC-Q100 automotive qualification, indicating its suitability for automotive-grade applications.
