Same model may have multiple batches, images only for reference.
DCP021212DP Real Image
Same model may have multiple batches, images only for reference.

DCP021212DP

Part No DCP021212DP
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC REG ISOLATED +/-12V 83MA 7DIP
Datasheet
DCP021212DP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series DCP02
Packaging Tube
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 83mA, 83mA
Power (Watts) - Manufacture Series 2W
Voltage - Isolation 1kV (1000V)
Applications ITE (Commercial)
Features OTP
Mounting Style Through Hole
Package 14-DIP (0.300", 7.62mm) (7 Leads)
Size / Dimension 0.78" L x 0.33" W x 0.21" H (19.7mm x 8.3mm x 5.3mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 88%
Power (Watts) - Max 384mW
Win Source Part Number 013862-DCP021212DP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DCP021212DP CAD Model

Description

DCP021212DP

The DCP021212DP is engineered to deliver dependable power conversion with excellent output stability and efficiency, suitable for evolving industrial demands.

Features and Benefits

  • High Conversion Efficiency: Maximizes energy use for better performance and reduced waste.
  • Dual Power Outputs: Facilitates power distribution to multiple circuit points.
  • Robust Design: Handles high load currents, increasing durability.
  • Thermal Management: Advanced design reduces overheating risk.

Applications

  • Automation Controls
  • Network Equipment
  • Aerospace Systems
  • Battery-powered Devices
Additional Information

This model optimizes space and energy use, making it an ideal choice for modern installations requiring consistent power supply solutions.
