Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Type Fanout Buffer (Distribution)
Number of Circuits 1
Input LVCMOS, LVDS, LVPECL, LVTTL
Output LVPECL
Frequency - Max 2GHz
Operating Supply Voltage 2.375 V ~ 3.6 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 16-VFQFN Exposed Pad
Manufacturer Package 16-QFN (3x3)
Win Source Part Number 1160653-CDCLVP1102RGTT
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Motor Drive & Control, Power Management
Family Name CDCLVP1102
Introduction Date May 01, 2009
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian CDCLVP1102RGTT CAD Model

Description

The CDCLVP1102RGTT is a state-of-the-art, dual-channel, high-speed clock buffer from Texas Instruments designed to address the stringent requirements of high-performance applications. Engineered to deliver low additive phase noise and low skew outputs, this device is an excellent choice for clock distribution in a wide array of digital systems.

Key Features

  • Dual Output Channels: The CDCLVP1102RGTT offers two low-skew, low-jitter outputs, enabling precise clock distribution to multiple components within a system.
  • Low Additive Phase Noise: This device is optimized to minimize phase noise, thereby improving signal integrity and system performance, especially in applications sensitive to timing variations.
  • Wide Frequency Range: It supports a broad range of input frequencies, making it a versatile solution for various applications, from networking and telecommunications to computing and data storage.
  • Flexible Power Supply: The CDCLVP1102RGTT operates on a supply voltage ranging from 2.5V to 3.3V, providing flexibility in different system power environments.
  • Small Footprint: Housed in a compact, 16-pin QFN package, this device saves valuable board space while delivering high performance.

Applications

The CDCLVP1102RGTT is ideal for use in a variety of applications, including but not limited to:

  • High-speed data converters
  • Wireless infrastructure
  • Test and measurement equipment
  • High-performance computing
  • Networking and telecommunications

Product Specifications

Parameter Value Supply Voltage (V<sub>CC) 2.5V - 3.3V Output Frequency Range Up to 2 GHz Package Type 16-pin QFN Operating Temperature Range -40°C to +85°C

With its robust design and advanced features, the CDCLVP1102RGTT from Texas Instruments is an outstanding choice for engineers looking to enhance their system's clock distribution with precision and reliability.
