The CD4515BM96 is a high-performance CMOS 4-bit latched/4-to-16 line decoder designed and manufactured by Texas Instruments. This integrated circuit is part of a family of devices that are widely used in digital systems where low power and high efficiency are required. The CD4515BM96 is especially suitable for implementing decoding and demultiplexing functions in various applications ranging from industrial electronics to personal computing devices.

Key Features

• Versatile Functionality: The device serves as a 4-bit latched decoder and a 4-to-16 line decoder, providing users with a flexible solution for their decoding needs.
• Low Power Consumption: With its CMOS technology, the CD4515BM96 ensures minimal power consumption, making it ideal for battery-operated and power-sensitive applications.
• High Noise Immunity: The inherent characteristics of CMOS provide high noise immunity, thus ensuring reliable performance even in electrically noisy environments.
• Wide Operating Voltage: It operates across a wide voltage range from 3V to 18V, accommodating various system requirements and simplifying power supply design.

Applications

The CD4515BM96 is versatile in its applications, including but not limited to:

• Data multiplexing
• Memory address decoding
• Binary-to-decimal decoding
• Control system signal routing

Package and Quality

The device is available in a 24-pin small outline package (SOP), identified by the suffix 'M96' in its part number, which is suitable for surface mount technology (SMT). The compact form factor of the SOP package allows for efficient use of board space in densely packed electronic assemblies.

As with all Texas Instruments products, the CD4515BM96 is manufactured to high-quality standards, ensuring reliability and performance consistency. The device is also supported by Texas Instruments' comprehensive technical resources, including datasheets, application notes, and online support, to assist designers in integrating this component into their projects.
