CD4097BE CMOS Analog Multiplexers/Demultiplexers by Texas Instruments

The CD4097BE is a versatile CMOS Analog Multiplexer/Demultiplexer component designed and manufactured by Texas Instruments. This integrated circuit is a pivotal element in various electronic applications that require the routing of analog or digital signals to and from multiple sources. The CD4097BE is known for its high degree of precision and reliability, making it an ideal choice for designers and engineers in the field.

Key Features:

• Multiple Channel Configurations: The device features a dual 8-channel configuration, which can be utilized as a multiplexer or a demultiplexer. This flexibility allows for efficient signal management in complex circuits.
• Wide Voltage Range: It operates over a wide voltage range from 3V to 18V, ensuring compatibility with a variety of logic families and making it suitable for both digital and analog applications.
• Low ON Resistance: The CD4097BE boasts a low ON resistance, typically around 100 ohms, which minimizes signal attenuation and preserves the integrity of the signal passing through the device.
• Binary Address Decoding: The selection of the desired channel is controlled by binary address decoding, which simplifies the integration of the device into digital systems.
• High Off-Isolation: The device ensures high off-isolation, which prevents signal leakage between channels and enhances the overall performance of the multiplexer/demultiplexer.
• Break-Before-Make Switching: The CD4097BE employs break-before-make switching, which eliminates the chance of shorting out adjacent channels during the transition, providing clean and glitch-free signal routing.

Applications:

• Signal routing in data acquisition systems
• Communication systems
• Test equipment
• Audio and video switching

The CD4097BE is available in a standard DIP-16 package, making it easy to integrate into both prototyping breadboards and final product designs. With its robust feature set, the CD4097BE from Texas Instruments stands out as a high-quality component for multiplexing and demultiplexing needs in a wide range of electronic systems.
