CD14538BPWR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Monostable
Independent Circuits 2
Schmitt Trigger Input Yes
Propagation Delay 100ns
Current - Output High, Low 6.8mA, 6.8mA
Supply Voltage - Operating 3 V to 18 V
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 16-TSSOP
Win Source Part Number 006234-CD14538BPWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CD14538BPWR CAD Model

Description

CD14538BPWR - Precision Monostable Multivibrator

Offering accurate timing, the CD14538BPWR is a dual monostable multivibrator designed for a range of timing applications. The device's configurability makes it ideal for any situation where precise pulse or delay generation is required.

Applications

  • Delay elements
  • Missing pulse detectors
  • Pulse shaping circuits
  • Pulse stretching applications

Features and Benefits

  • Versatile voltage range (3V to 15V)
  • Strong noise immunity
  • Low power requirement
  • Flexible pulse width
  • Synchronous reset capability

Engineered for precision, the CD14538BPWR stands out in systems requiring exacting timing and pulse conversion solutions.
