Products specifications

Categories RF/IF and RFID
Manufacturer Texas Instruments
Packaging Reel - TR
Package 80-TQFP Exposed Pad
Manufacturer Package 80-HTQFP (12x12)
Win Source Part Number 1141777-ADS58C20IPFPR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name ADS58C20
Introduction Date March 01, 2011
ECCN 5A991.b.1
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ADS58C20IPFPR CAD Model

Description

The Texas Instruments ADS58C20IPFPR is a high-performance, dual-channel analog-to-digital converter (ADC) that offers exceptional dynamic range and accuracy, making it an ideal choice for a wide range of demanding applications. This state-of-the-art ADC features a 14-bit resolution and a maximum sampling rate of up to 20 MSPS (Mega Samples Per Second), ensuring precise digitization of analog signals for high-speed signal processing tasks.

Key Features

  • High Resolution: With a 14-bit resolution, the ADS58C20IPFPR provides fine detail in signal conversion, which is crucial for applications requiring high levels of precision.
  • Fast Sampling Rate: The device supports a sampling rate of up to 20 MSPS, allowing for the capture of high-frequency signals without loss of fidelity.
  • Dual-Channel: The dual-channel design enables simultaneous sampling of two analog signals, which is beneficial for systems that require multi-channel input with synchronous sampling.
  • Low Power Consumption: Designed with power efficiency in mind, this ADC operates with a low power consumption, making it suitable for portable and battery-powered applications.
  • Flexible Interface: It features a parallel LVDS (Low-Voltage Differential Signaling) output interface, providing high-speed data transfer with reduced noise.

Applications

The ADS58C20IPFPR is versatile and can be used in a variety of applications, including:

  • Wireless communication systems
  • Radar and satellite communication
  • Medical imaging systems
  • Test and measurement equipment
  • Digital storage oscilloscopes

Product Packaging and Availability

The ADS58C20IPFPR is available in a QFP (Quad Flat Package) and is designated with the part number suffix 'IPFPR'. This package is designed for surface mount technology, enabling compact and reliable integration into a wide range of electronic systems. For pricing, samples, and additional information, interested parties should contact Texas Instruments or authorized distributors.
