The ADCS7476AIMFX/NOPB is a high-performance, low-power, 12-bit analog-to-digital converter (ADC) offered by Texas Instruments. This component is part of a family of micro-power octal unbuffered voltage-output 8-bit digital-to-analog converters (DACs) that operate from a single 2.7 to 5.5V supply and are guaranteed monotonic by design.

Key Features

• Resolution: 12-bit resolution provides high precision for a wide range of applications.
• Sampling Rate: Fast conversion rate of up to 1 MSPS (mega-samples per second) enables real-time data processing.
• Power Consumption: Ultra-low power consumption makes it ideal for battery-powered and portable applications.
• Supply Voltage Range: Wide supply voltage range from 2.7V to 5.5V offers flexibility in system design.
• Interface: SPI-compatible serial interface ensures easy integration with most microcontrollers.
• Package: Available in a small X2QFN package, it saves board space and is suitable for space-constrained applications.
• Temperature Range: Industrial temperature range of -40°C to 85°C allows operation in harsh environments.
• No Missing Codes: Guaranteed no missing codes over the full operating temperature range.
• Lead-Free and RoHS Compliant: The device is available in a lead-free package and is fully RoHS compliant, making it suitable for eco-friendly applications.

Applications

The ADCS7476AIMFX/NOPB is designed for a variety of applications, including:

• Data acquisition systems
• Battery-powered instruments
• Medical instruments
• Handheld test equipment
• Portable consumer electronics

With its high level of integration and performance, the ADCS7476AIMFX/NOPB from Texas Instruments is the ideal choice for designers looking to add precise data conversion to their systems without compromising on power efficiency or space.
