RS612-0.5-02

Part No RS612-0.5-02
Manufacturer TE Connectivity
Catalog Common Mode Chokes
Description CMC 200UH 500MA 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 200 µH @ 1 kHz
Current Rating (Max) 500mA (Typ)
DC Resistance (DCR) (Max) 650mOhm (Typ)
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Approval Agency UR, VDE
Mounting Type Through Hole
Size / Dimension 0.709" L x 0.492" W (18.00mm x 12.50mm)
Height (Max) 0.787" (20.00mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1530606-RS612-0.5-02
Ultra Librarian 3D Model Ultra Librarian RS612-0.5-02 CAD Model
