IM07GR TE Connectivity IM07GR Real Image IM07GR label picture 2 IM07GR real image
Same model may have multiple batches, images only for reference.
IM07GR TE Connectivity IM07GR Real Image IM07GR label picture 2 IM07GR real image
IM07GR TE Connectivity IM07GR Real Image IM07GR label picture 2 IM07GR real image
Same model may have multiple batches, images only for reference.

IM07GR

Part No IM07GR
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description RELAY TELECOM DPDT 2A 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Reel - TR
Status Active
Relay Type Telecom
Coil Type Non Latching
Coil Current 8.3mA
Coil Voltage 24VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 18 VDC
Turn Off Voltage (Min) 2.4 VDC
Operate Time 3ms
Release Time 3ms
Features Sealed - Hermetically
Mounting SMD (SMT)
Termination Style Gull Wing
Coil Power 200 mW
Coil Resistance 2.88 kOhms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 1045378-IM07GR
Family Name IM
Introduction Date January 15, 2008
ECCN EAR99
Country of Origin Portugal
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Signal Processing, Communications & Networking, Consumer Electronics, Test & Measurement, Automation & Process Control, Medical, HVAC
Ultra Librarian 3D Model Ultra Librarian IM07GR CAD Model

Description

The TE Connectivity Potter & Brumfield Relays IM07GR is a DPDT (2 Form C) telecom relay with a coil voltage of 24VDC and coil resistance of 2.88 kOhms.

  • Coil Type: Non-Latching
  • Coil Current: 8.3mA
  • Coil Power: 200mW
  • Switching Voltage: 250VAC, 220VDC Maximum
  • Contact Rating: 2A
  • Seal Type: Sealed-Hermetically
  • Termination Style: Gull Wing
  • Mounting Type: SMD (SMT)
  • Operate Time: 3ms
  • Release Time: 3ms
  • Category: Relays
  • Product Status: Active
  • Supply and Demand Status: Limited
  • Applications: Industrial, Signal Processing, Communications & Networking, Consumer Electronics, Test & Measurement, Automation & Process Control, Medical, and HVAC
