IM03GR TE Connectivity IM03GR label picture 2 IM03GR real image4685 IM03GR Real Image IM03GR real image IM03GR label picture
Same model may have multiple batches, images only for reference.
IM03GR TE Connectivity IM03GR label picture 2 IM03GR real image4685 IM03GR Real Image IM03GR real image IM03GR label picture
IM03GR TE Connectivity IM03GR label picture 2 IM03GR real image4685 IM03GR Real Image IM03GR real image IM03GR label picture
Same model may have multiple batches, images only for reference.

IM03GR

Part No IM03GR
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description RELAY TELECOM DPDT 2A 5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Reel - TR
Status Active
Relay Type Telecom
Coil Type Non Latching
Coil Current 28mA
Coil Voltage 5VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 3.75 VDC
Turn Off Voltage (Min) 0.5 VDC
Operate Time 3ms
Release Time 3ms
Features Sealed - Hermetically
Mounting SMD (SMT)
Termination Style Gull Wing
Coil Power 140 mW
Coil Resistance 178 Ohms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 124512-IM03GR
Family Name IM
Introduction Date November 19, 2007
ECCN EAR99
Country of Origin Austria
Halogen Free Not Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IM03GR CAD Model

Description

The TE Connectivity Potter & Brumfield Relays 124512-IM03GR is a DPDT (2 Form C) relay with a coil voltage of 5VDC and a contact rating of 2A.

  • Switching Voltage: 250VAC, 220VDC - Max
  • Turn On Voltage: 3.75 VDC
  • Turn Off Voltage: 0.5 VDC
  • Operate Time: 3ms
  • Suitable for Use In: various applications including telecom
  • Temperature Range: -40°C to 85°C
  • Features: hermetically sealed
