Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Terminal Type Standard
Stud/Tab Size 1/2 Stud
Terminal Style Two Stud Holes
Tab Thickness 0.200" (5.08mm)
Length - Overall 4.800" (121.92mm)
Width - Outer Edges 1.800" (45.72mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp, Barrel
Wire Gauge 500MCM (kcmil)
Insulation Non-Insulated
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1635707-327289
Ultra Librarian 3D Model Ultra Librarian 327289 CAD Model
