Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Connector Type Header, Male Pins and Blades
Number of Positions 35
Number of Positions Loaded All
Pitch 0.079" (2.00mm)
Mounting Type Board Edge, Through Hole, Right Angle
Termination Press-Fit
Contact Layout, Typical 25 Signal, 10 Power
Features Mating Guide
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Color Black
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1612594-1926736-2
Ultra Librarian 3D Model Ultra Librarian 1926736-2 CAD Model
