1571999-6 TE Connectivity
Same model may have multiple batches, images only for reference.

1571999-6

Part No 1571999-6
Manufacturer TE Connectivity
Catalog DIP Switches
Description SWITCH PIANO DIP SPST 25MA 24V / Dip Switch SPST 4 Position Through Hole, Right Angle Piano Actuator 25mA 24VDC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>DIP Switches
Mfr TE Connectivity ALCOSWITCH Switches
Series ADP
Package Tube
Circuit SPST
Number of Positions 4
Current Rating (Amps) 25mA
Voltage Rating 24VDC
Actuator Type Piano
Actuator Level Raised
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.287" (7.30mm)
Mounting Type Through Hole, Right Angle
Termination Style PC Pin
Pitch 0.100" (2.54mm), Full
Washable Yes
Temperature Range - Operating -30°C ~ 85°C
Body Material Polyphenylene Sulfide (PPS)
Length 0.478" (12.14mm)
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Base Product Number 1571999
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.50.9065
Other Names 450-1356,ADP0404
Standard Package 35
Win Source Part Number 1157593-1571999-6
Ultra Librarian 3D Model Ultra Librarian 1571999-6 CAD Model

Description

The TE Connectivity ALCOSWITCH Switches ADP0404 is a DIP switch with 4 positions and a pitch of 0.100" (2.54mm), full.

  • Positions: 4
  • Pitch: 0.100" (2.54mm)
  • Termination Style: PC pin
  • Actuator Type: Raised
  • Contact Material: Copper alloy
  • Body Material: Polyphenylene sulfide (PPS)
  • Washable: Yes
  • Operating Temperature: -30°C ~ 85°C
