1-776228-1 Real Image
Same model may have multiple batches, images only for reference.

1-776228-1

Part No 1-776228-1
Manufacturer TE Connectivity
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 23POS 4MM  /  Connector Header Panel Mount, Through Hole 23 position 0.157" (4.00mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series AMPSEAL
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.157" (4.00mm)
Number of Positions 23
Number of Rows 3
Row Spacing - Mating 0.157" (4.00mm)
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Panel Mount, Through Hole
Termination Solder
Fastening Type Locking Ramp
Contact Shape Circular
Contact Finish - Mating Gold-Palladium
Contact Material Brass
Insulation Material Polybutylene Terephthalate (PBT), Glass Filled
Features Mounting Flange, Sealed
Temperature Range - Operating -40°C ~ 125°C
Insulation Color Black
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 250VAC
Applications Automotive, Industrial
Base Product Number 776228
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names -1-776228-1-SI,A105199,-1-776228-1-CSI,17762281,1-776228-1-ND
Standard Package 40
Win Source Part Number 1009401-1-776228-1
Ultra Librarian 3D Model Ultra Librarian 1-776228-1 CAD Model

Description

The TE Connectivity AMP Connectors 776228 is a 23-position header connector that belongs to the AMPSEAL series.

  • Pitch: 0.157 inches (4.00mm)
  • Color: Black
  • Features: Mounting Flange, Sealed, Header
  • Contact Type: Male Pin
  • Termination: Solder
  • Fastening Type: Locking Ramp
  • Contact Material: Brass
  • Contact Finish: Gold-Palladium
  • Voltage Rating: 250VAC
  • Current Rating: Varies depending on wire gauge
  • Operating Temperature: -40°C to 125°C
  • Win Source Part Number: 1009401-1-776228-1
