The PF500A-360 is an AC DC converter module from TDK-Lambda Americas Inc.. It is part of the PF (500W) series, which belongs to the power supplies - board mount - AC DC converters category.

• Series: PF (500W)
• Application: ITE (Commercial)
• Package: Enclosed Module
• Size / Dimension: 3.27" L x 3.39" W x 0.16" H (83.0mm x 86.0mm x 4.0mm)
• Power (Watts): 500 W
• Input Voltage: 85V ~ 265V AC
• Number of Outputs: 1
• Current - Output (Max): 1.4A
• Voltage - Output: 360V
• Efficiency: 95%
• Mounting Type: Through Hole
• Operating Temperature: -20°C ~ 85°C
• Standards: CE, cULus, 60950-1, 62368-1
• Product Status: Active
• California Prop 65: Yes
