ALD-214012PJ111

Part No ALD-214012PJ111
Manufacturer TDK-Lambda Americas Inc.
Catalog External/Internal (Off - Board) LED Drivers
Description LED DRIVER CC BOOST 44V 140MA
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Not For New Designs
Programmable Not Verified
Type Constant Current
Topology Boost
Number of Outputs 2
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 44V (Max)
Current - Output (Max) 140mA
Power (Watts) 6 W
Dimming Analog, PWM
Features Remote On/Off, OVP
Temperature Range - Operating -30°C ~ 85°C
Termination Style Connector
Size / Dimension 3.35" L x 0.85" W x 0.20" H (85.0mm x 21.5mm x 5.0mm)
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1542470-ALD-214012PJ111
Ultra Librarian 3D Model Ultra Librarian ALD-214012PJ111 CAD Model
