DEA202025LT-5052C1 TDK Corporation DEA202025LT-5052C1 real image
Same model may have multiple batches, images only for reference.
DEA202025LT-5052C1 TDK Corporation DEA202025LT-5052C1 real image
DEA202025LT-5052C1 TDK Corporation DEA202025LT-5052C1 real image
Same model may have multiple batches, images only for reference.

DEA202025LT-5052C1

Part No DEA202025LT-5052C1
Manufacturer TDK Corporation
Catalog RF Filters
Description RF FILTER LOW PASS MULT LAY 0805
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - RF Filters
Mfr TDK Corporation
Series DEA
Package Tape & Reel
Product Status Active
Bandwidth 145MHz
Filter Type Low Pass
Insertion Loss 1.3dB
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 3 PC Pad
Size / Dimension 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height (Max) 0.031" (0.80mm)
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 718214-DEA202025LT-5052C1
Ultra Librarian 3D Model Ultra Librarian DEA202025LT-5052C1 CAD Model

Description

The 718214-DEA202025LT-5052C1 is an RF filter from TDK Corporation.

  • Series: DEA
  • Type: Low Pass Filter
  • Frequency: 145MHz
  • Bandwidth: 145MHz
  • Suitable for: Various wireless communication systems
  • Insertion Loss: 1.3dB
  • Size: 0.079" L x 0.049" W (2.00mm x 1.25mm)
  • Mounting: Surface Mountable
  • Packaging: Tape & Reel (2,000 pcs)
  • Applications: RF and Wireless Applications
